Micro-Framed 3 and Micro-Framed 4 are architectural loudspeakers developed for indoor distributed audio applications, designed to integrate discreetly into living rooms, bedrooms, offices, gourmet areas, and high-end residential environments. Inspired by the NoFrame philosophy, the line combines an ultra-slim profile with premium anodized finishes, allowing elegant integration into the architectural plane of drywall ceilings or wood panels.
The difference between the models lies in the acoustic scale and sound extension of each solution. Micro-Framed 3, equipped with a 3" full-range driver, offers a more compact and discreet approach for distributed audio applications in smaller environments. Micro-Framed 4, featuring a 4" full-range driver, expands sound presence and frequency extension while maintaining the same minimalist identity of the line. Both models deliver clear reproduction, stable imaging, and uniform coverage across different types of environments.
The aluminum structure with open baffle architecture ensures lightness, durability, easy installation, and refined visual integration into the ceiling. The line is available in premium anodized finishes, reinforcing the minimalist and architectural proposal of the series.
Micro-Framed 3 & 4
Indoor
S P E C I F I C A T I O N S

DIMENSIONS
• Micro-Framed 3

Final Dimensions (WxH): 4.1" x 4.1" | 105 x 105mm
Cutout (WxH): 3.7" x 3.7" I 93 x 93mm
Depth: 2.4" | 60mm
• Micro-Framed 4

Final Dimensions (WxH): 4.6" x 4.6" I 118 x 118mm
Cutout (WxH): 4.2" x 4.2" I 106 x 106mm
Depth: 2.5" | 65mm
Design & Finish Options

Finish Colors
CABINET

Painted Aluminum
Anodized

GRILL

Painted Aluminum
