All e STR

MINI BLOCK

Miniblock ALL is an amplifier with different configurations in one single piece, allowing the dealer to optimize its inventory and installation.

In the same amplifier, it is possible to configure it as Full Range, High Pass Filter (HPF), and Low Pass Filter (LPF), always allowing a proper installation of the speaker or subwoofer, making it the ideal solution for installers.

Its power supply uses PFC technology to extend its lifetime and provide no interruptions operation from 90V to 260V

The Direct Power technology enables installers to provide clear audio quality, handling all the harmonics.


All

Miniblock STR has the same form factor as the ALL version. It has two channels of 120W @ 4 Ohms or 80W @ 8 Ohms.

The stereo version of the Miniblock also has Direct Power technology, easing the installs. It provides clear audio, handling the harmonics exceptionally well.

The STR uses a PFC technology for the power supply, allowing it to operates from 90V to 260V with no interrupion, extending the lifetime of the amplifier.

S P E C I F I C A T I O N S

2 "

43mm

4.9 "

185mm

medida miniblock.png

8.1 "   I   146mm

MINIBLOCK STR

Enclosure
Aluminum



Sensitivity Input

0.750mV (0dB)

2 channel de 120Wrms /4Ω 33/66ms @ 1KHz tone burst;
2 channel de 80Wrms/8Ω 33/66ms


THD+N and SMPTE IMD less than 0,1%;


Impedance Output

< 5mΩ (damping > 200);


SNR better than 110dBA;


Slew rate > 30V/us;


Maximum consumption 0,4kVA;

MINIBLOCK ALL

Enclosure
Aluminum



Sensitivity Input

0.200mV (-12dB)

160Wrms/4Ω 33/66ms @ 1KHz tone burst;

112Wrms/8Ω 33/66ms

64Wrms/16Ω 33/66ms

THD+N and SMPTE IMD lower than 0,1%;

Impedance Output
< 5mΩ (damping > 200);

SNR better than 110dBA;

Slew rate > 30V/us;

Maximum consumption: 0,4kVA;



C O L O R
